∴ Details

• Display
  Screen : 70.7X38.8 LCD Display
  11-segment pulse amplitude bar
  Maximum 72 Hours trend function
  Numeric data display : High SAT, High Rate, Low SAT, Low Rate,Current Rate, SAT Alarms On/Off

  Range
  Saturation : 0~100%
  Pulse Rate : 30~250bpm(beats per minute)

  Power Requirements
  9V DC 4.6Amps 100~240 VAC, 50/60Hz
  Less than 24W power consumption

  Battery Pack
  Lithium lon Battery
  4 hours operation when fully charged

  Output
  RS-232C port : Trend Data (SpO2 and pulse rate, Interval)

  Trend Memory
  Saturation and Pulse rate Memories(72 hours maximum)

  Physical Dimension
  45mm(H)X190mm(W)X88mm(D)
  Weight : 286g, 346g(Include Battery)

  Environmental
  Operating Temperature 10℃ ~ 45℃(50℉~113℉)
  Storage Temperature -10℃~ 50℃(14℉~122℉)
  Operating Humidity 30% ~ 85% non condensing
  Storage Humidity 20% ~ 95% non condensing
